SyRen DIP switch wizard
When using multiple SyRens, make S2 high to select the SyRen to receive
the command. Serial bytes are 8N1, and you can choose from the
following baud rates:
(Lithium mode)
Baud |
|
2400 |
![](multiple2400bps.jpg) |
9600 |
![](multiple9600bps.jpg) |
19200 |
![](multiple19200bps.jpg) |
38400 |
![](multiple38400bps.jpg) |
9600 is usually the best place to start. Please see the manual for a wiring diagram.
